20ft High Cube Open Top Shipping Container — First-Trip
First-trip version, this 20 ft Open Top High Cube container offers 36.5 m3 with a tarpaulin roof and increased height, certified new condition. Maximum quality solution for vertical loading of tall, indivisible parts.
- Dimensions (LxWxH)
- 6.1 m × 2.4 m × 2.9 m
- Floor area
- 13,7 m²
- Volume
- 36,5 m³
Custom-built
Standard and custom-built modules, individually or assembled.
Expertise
Industry experts to support you with your project.
Express delivery
Reliable and secure transport — a logistics team dedicated to your project.
Competitive pricing
Depots across France, close to you.
Compliance
ISO 9001 and CSC standards.
Devis gratuit
Demander un devis pour ce conteneur
Réponse d'un interlocuteur dédié sous 4 h ouvrées, au prix du marché.
Demande envoyée !
Votre demande a bien été reçue et sera traitée sous 4 h ouvrées. Pour une réponse immédiate, appelez-nous au +33 9 78 45 18 90.
A project involving a container?
Answer 5 questions — we'll guide you to the ideal solution.
Similar products
20ft Open Top Shipping Container — First-Trip
20ft Open Top Shipping Container — Used
40ft Open Top HC Shipping Container — First-Trip
40ft High Cube Open Top Shipping Container — Used
Technical specifications
| External dimensions | 6,058 m × 2,438 m × 2,896 m |
|---|---|
| Internal dimensions | 5,890 m × 2,340 m × 2,650 m |
| Door clearance | 2,340 m × 2,585 m |
| Tare weight | 2 450 kg |
| Payload | 28 030 kg |
| Volume | 36,5 m³ |
| Floor area | 13,7 m² |
| Materials | Corten steel |
| Floor type | Marine plywood |
| Door opening | Movable lintel |
| Certifications | CSC |
| Type | Conteneur Open Top |
| Reference (SKU) | conteneur-20-pieds-open-top-hc-premier-voyage |
FAQ
What is the lifespan of a container?
Can a container be customized?
Do you offer rental?
What payment methods do you accept?
In detail
What is a 20ft first-trip Open Top HC container?
An Open Top container is a container with an opening roof: its top section is removed to load goods from above, by crane. "HC," for High Cube, refers to a format raised by about 30 cm compared with the standard. "First-trip" means it is a new unit, out of the factory after a single trip.
The body, made of Corten steel, a self-weathering steel that naturally resists marine corrosion, is fully welded. The reinforced polyester tarpaulin rests on removable metal bows. This HC variant has a movable header: the crossbar above the rear doors pivots, which allows tall pieces to be brought in through the rear without removing the roof.
The 20ft HC format offers 36.5 m³ of usable volume, 3.5 m³ more than a standard 20ft Open Top, for a 28,030 kg allowable load. Its interior height of 2.65 m accommodates out-of-gauge vertical pieces, loaded through the doors as well as the roof.
In detail
Open Top: what is an opening roof for?
A standard container is loaded only through its rear doors. Any goods taller than these doors, beam, machine, tank, become "out of gauge," or OOG: they do not fit. This is the problem the Open Top solves.
Its roof is not a fixed steel sheet. It consists of removable metal bows and a polyester tarpaulin tensioned by straps. Both are removed, and the body opens completely from the top. A crane, an overhead crane or a hoist can then lower the load directly in, without cutting it up or passing it through the doors.
Applications
Uses for a 20ft first-trip Open Top HC container
The HC format combines two loading modes: the removed roof for crane access, and the pivoting movable header for the rear doors.
The applications below show in which contexts this format is most relevant. Each use links the on-the-ground need to the container's concrete benefit.
Highlights
Why buy a 20ft first-trip Open Top HC container
The new 20ft Open Top HC combines two out-of-gauge accesses, the opening roof and the movable header, with the increased High Cube height. The strengths below explain what each feature brings and why this configuration accommodates the tallest vertical pieces.
The strengths below explain what each technical choice brings to the project. They help compare the product with a less specialized alternative or a different condition.
-
Additional HC height
2.65 m of interior height, 30 cm more than a standard Open Top. This vertical margin accommodates tall pieces that the standard format cannot hold.
-
New opening roof
The bows and tarpaulin come off to free full access from above. The load is lowered vertically by crane, directly into the body.
-
Movable header
The rear header pivots to let tall pieces pass through the rear, with no need to remove the roof. It is a second, complementary out-of-gauge access route.
-
Compatible with crane, overhead crane and hoist
Standard vertical handling applies with no adaptation. The container loads on docks as well as on industrial sites.
-
Welded Corten body
The self-weathering steel structure withstands maritime conditions and repeated handling impacts. Robustness is not compromised by the openings.
-
ISO 6346 and CSC compliance
The unit is fit for multimodal transport. Its High Cube gauge, however, requires checking available heights on certain routes with low bridges.
Applications
What is the price of a 20ft first-trip Open Top HC container
The new 20ft Open Top HC combines three specifications, opening roof, movable header and HC height, which place it in a restricted niche segment of the out-of-gauge market.
Four factors influence price variations:
The factors below explain why the price can vary from one quote to another. They help read a quote by distinguishing the price of the product, availability and delivery costs.
Delivery
Delivery & logistics
National Conteneur delivers throughout mainland France and internationally. Lead times and conditions vary by zone and mode of transport.
